PA6H MTK MT3339
|
3 訂單數量
發貨方式
--->>>到達時間 5-7天
--->>>到達時間 15-27天
--->>>到達時間 5-7天
主營全新原裝正品現貨，訂貨，註冊會員提交詢價可以了解到最新產品報價。^_^
產品詳情
| 型號 | PA6H |
| 品牌 | - |
| 年份 | N/A |
| 描述 | MTK MT3339 |
 規格書 | 點擊查看 |
Product Description
|
Description
|
|
GPS Solution
|
MTK MT3339
|
|
Frequency
|
L1, 1575.42MHz
|
|
Sensitivity1
|
Acquisition: -148dBm, cold start
Reacquisition: -163dBm, Hot start
Tracking: -165dBm
|
|
Channel
|
66 channels
|
|
TTFF
|
Hot start: 1 second typical
Warm start: 33 seconds typical
Cold start: 35 seconds typical
(No. of SVs>4, C/N>40dB, PDop<1.5)
|
|
Position Accuracy
|
Without aid:3.0m (50% CEP)
DGPS(SBAS(WAAS,EGNOS,MSAS)):2.5m (50% CEP)
|
|
Velocity Accuracy
|
Without aid : 0.1m/s
DGPS(SBAS(WAAS,EGNOS,MSAS,GAGAN)):0.05m/s
|
|
Timing Accuracy
(1PPS Output)
|
10 ns(Typical )
|
|
Altitude
|
Maximum 18,000m (60,000 feet)
|
|
Velocity
|
Maximum 515m/s (1000 knots)
|
|
Acceleration
|
Maximum 4G
|
|
Update Rate
|
1Hz (default), maximum 10Hz
|
|
Baud Rate
|
9600 bps (default)
|
|
DGPS
|
SBAS(defult) [WAAS, EGNOS, MSAS,GAGAN]
|
|
QZSS
|
Support(Ranging)
|
|
AGPS
|
Support
|
|
Power Supply
|
VCC:3.0V to 4.3V;VBACKUP:2.0V to 4.3V
|
|
Current Consumption
|
25mA acquisition, 20mA tracking
|
|
Working Temperature
|
-40 °C to +85 °C
|
|
Dimension
|
16 x 16x 4.7mm, SMD
|
|
Weight
|
4g
|
-
